MACKAY - PU SERIES
The PU Series comprises of a galvanized steel trailer incorporating a separate independent sub frame chassis, providing the trailer with exceptional features and top class functionality. There is also an adjustable rear tilting rocka roller system for quick and easy launch retrieve capabilities. Multi Roller design makes it easy to roll on roll off at the ramps.
Suitable for boats 4.6m to 7.8m. Single and tandem axle available.
Suitable for boats up to 5.1M:
PU4750-13-M Single Axle Mechanical Brakes GTM: 1,350kg
PU4750-14-M Single Axle Mechanical Brakes GTM: 1,480kg
Suitable for boats up to 5.5M:
PU5000-13-M Single Axle Mechanical Brakes GTM: 1,350kg
PU5000-14-M Single Axle Mechanical Brakes GTM: 1,480kg
PU5000-14HX-M Single Axle Mechanical Brakes GTM: 1,650kg
PU5000T-13-M Tandem Axle Mechanical Brakes GTM: 1,850kg
Suitable for boats up to 5.8M:
PU5500-13-M Single Axle Mechanical Brakes GTM: 1,350kg
PU5500-14HX-M Single Axle Mechanical Brakes GTM: 1,650kg
PU5500-14HD-M Single Axle Mechanical Brakes GTM: 1,750kg
PU5500T-13-M Tandem Axle Mechanical Brakes GTM: 1,850kg
Suitable for boats up to 6.1M:
PU5750T-13-M Tandem Axle Mechanical Brakes GTM: 1,999kg
PU5750T-14-M Tandem Axle Mechanical Brakes GTM: 1,999kg
PU5750T-14-HB Tandem Axle Electric Brakes GTM: 2,600kg
PU5750T-14-HB Tandem Axle Electric Brakes GTM: 3,000kg
PU5750T-14LS-HB Tandem Axle Electric Brakes GTM: 3,200kg
Suitable for boats up to 6.5M:
PU6000T-13-M Tandem Axle Mechanical Brakes GTM: 1,999kg
PU6000T-14-HB Tandem Axle Electric Brakes GTM: 2,600kg
PU6000T-14LS-HB Tandem Axle Electric Brakes GTM: 3,200kg
PU6000T-15HD-HB Tandem Axle Electric Brakes GTM: 3,500kg
Suitable for boats up to 7.0M:
PU6500T-14LS-HB Tandem Axle Electric Brakes GTM: 3,200kg
PU6500T-15HD-HB Tandem Axle Electric Brakes GTM: 3,500kg
PU6500T-15HDE-HB Tandem Axle Electric Brakes GTM: 3,750kg
Suitable for boats up to 7.4M:
PU7000T-14LS-HB Tandem Axle Electric Brakes GTM: 3,200kg
PU7000T-15HD-HB Tandem Axle Electric Brakes GTM: 3,500kg
PU7000T-15HDE-HB Tandem Axle Electric Brakes GTM: 3,750kg
PU7000T-15HD-HB Tandem Axle Electric Brakes GTM: 4,000kg
PU7000T-15XDE-HB Tandem Axle Electric Brakes GTM: 4,499kg
Suitable for boats up to 7.8M:
PU7500T-15HD-HB Tandem Axle Electric Brakes GTM: 3,500kg
PU7500T-15HDE-HB Tandem Axle Electric Brakes GTM: 3,750kg
PU7500T-15HD-HB Tandem Axle Electric Brakes GTM: 4,000kg
PU7500T-15XHD-HB Tandem Axle Electric Brakes GTM: 4,499kg
PU7500TR-14LS-HB Tri Axle Electric Brakes GTM: 4,499kg
PU7500TR-15HD-HB Tri Axle Electric Brakes GTM: 4,499kg
PU Series Features:
Galvanized steel frame with two years structural warranty
Galvanized steel springs, axles & disk hubs
Transom tie down points
Integral retrieval system
Independent subframe for strength & stability
Galvanized steel wheels
Light truck tyres
Load sharing suspension on Heavy Duty models
Swing up jockey wheel
LED Lights & LED Clearance lights
Adjustable tilting Rear Rocka for full drive-on capability
Fully adjustable side wobble rollers
Photos are for illustration purposes and may include optional upgrades.
Specifications are subject to change due to consistent updates and improvements to each model. Mackay is also a custom builder which means that specifications are commonly changed to meet each customers requirements. We recommend when choosing your trailer to speak with our sales team to ensure you select the right trailer for your needs.
